SKU: QRS110/54SS

Intumescent Slim Fire Sleeve | QRS

Description

The QRS Fire Sleeve is specifically developed to help prevent the spread of fire through plastic ventilation ducts as they pass through compartment lines.

Built with a tough pressed steel outer shell and a high-performance graphite-based intumescent core, the sleeve reacts instantly when exposed to fire. The intumescent material expands rapidly, closing the duct opening and maintaining the integrity of the fire barrier once the plastic duct has melted away.

Versatile in its application, the sleeve can be retrofitted to existing ducts, installed in clusters to protect multiple penetrations, and is fully compatible with the QuelStop Fire Batt system.

Standards & Approvals

Building Regulations impose limitations on all pipes passing through fire compartment walls and floors.

QRS Vent Duct Slim Sleeves allow plastic ducts to meet the requirements of the Building Regulations.

QRS Vent Duct Slim Sleeves have been tested according to BSEN 1366-3 where various plastic duct sizes have met insulation and integrity criteria for this standard for up to 2 hours.

NBS logo on a white background.

Quelfire QRS Intumescent Fire Sleeves are designed for use where plastic ventilation ducts pass through fire-rated walls, helping to maintain compartmentation and prevent the spread of fire and smoke.

The QRS Fire Sleeve requires no mechanical fixings or additional framework. Instead, it relies on the integrity of the fire-rated wall construction—whether plasterboard, solid masonry/block, or the QuelStop Fire Batt system—to hold it securely in place. For best performance, penetrations should be cut as tightly as possible to the sleeve itself. Approximate aperture sizes are provided in the Specification Details table below.

  • Fire Rating

    Up to 2 hours (EI 120)
    EI 120 was achieved using specific testing configurations. Please check the tested scope.

  • Delivery

    Next Day Delivery
    Orders placed before 2pm on weekdays will be sent the same day for delivery next working day.*

  • Stock Status

    In Stock & Ready to Go
    Except for custom-made items which will be made to order.

*Please note that custom made items can expect to have longer lead times. Next working day is typical but can depend on outside factors not controlled by Quelfire.

  • CE mark logo.

    CE Mark

    CE marking logo shows that a product meets the health, safety, and environmental requirements of the European Economic Area (EEA) and can be freely traded within the EEA market. CE marking is a voluntary requirement for passive protection penetration seals.

  • Warringtonfire logo.

    BS EN 1366-3 tested

    The Warringtonfire logo is evidence that this product was BS EN 1366-3 fire resistance tested at a Warringtonfire accredited test laboratory.

Product Info & Features

Product Information
Specification Details
Composition The QRS Vent Duct Slim Sleeves consist of a flexible galvanised steel shell containing graphite-based intumescent material. Manufactured to suit flat ducts of 110x54mm, 205x60mm, and 220x90mm.
Durability Tested to Type X durability, allowing installation in conditions exposed to weathering. Designed to last the lifetime of the building.
Features & Benefits
  • Tick Tested to BSEN 1366-3
  • Tick Tested with Uncapped/Uncapped (U/U) duct configurations as required for ventilation ducts
  • Tick Up to 2 hour fire rating
  • Tick Slimline: saves ceiling space
  • Tick Suitable for masonry walls or plasterboard partitions
  • Tick Suitable for insulated and non-insulated partitions
  • Tick Can be retrofitted
  • Tick No mechanical fixings required
  • Tick Robust galvanised steel shell
  • Tick Performance unaffected by weathering (Type X Durability)
Show Product Info & Features and Benefits â–¼
Product Information
Specification Details
Composition The QRS Vent Duct Slim Sleeves consist of a flexible galvanised steel shell containing graphite-based intumescent material. Manufactured to suit flat ducts of 110x54mm, 205x60mm, and 220x90mm.
Durability Tested to Type X durability, allowing installation in conditions exposed to weathering. Designed to last the lifetime of the building.
Features & Benefits
  • Tick Tested to BSEN 1366-3
  • Tick Tested with Uncapped/Uncapped (U/U) duct configurations as required for ventilation ducts
  • Tick Up to 2 hour fire rating
  • Tick Slimline: saves ceiling space
  • Tick Suitable for masonry walls or plasterboard partitions
  • Tick Suitable for insulated and non-insulated partitions
  • Tick Can be retrofitted
  • Tick No mechanical fixings required
  • Tick Robust galvanised steel shell
  • Tick Performance unaffected by weathering (Type X Durability)

Specification Details

Product Code Duct Size (mm) Space Needed Around Duct (mm) Recommended Aperture (mm) QRS Length (mm)
QRS110/54SS 110 x 54 8 126 x 70 140
QRS204/60SS 204 x 60 8 219 x 75 140
QRS220/90SS 220 x 90 12 244 x 114 140
Product Code Duct Size (mm) Space Needed Around Duct (mm) Recommended Aperture (mm) QRS Length (mm)
QRS110/54SS 110 x 54 8 126 x 70 140
QRS204/60SS 204 x 60 8 219 x 75 140
QRS220/90SS 220 x 90 12 244 x 114 140

Product Documentation

File
Product Data Sheet Download
Installation Instructions Download
