Ablative Coated Fire Batt is a specially designed insulation batt that acts as an air seal barrier whilst reinforcing fire resistance and acoustic performance of concrete floors, masonry walls and drylining systems.

The Ablative Coating is used in conjunction with the Ablative Coated batt to enhance fire performance. It can also be used in additional fire stopping applications such as linear and trapezoidal applications to provide an effective seal to inhibit the passage of smoke.

An ablative material develops a char that has thermal insulation characteristics and resists erosion from fire and flames.

An accelerant is a material, usually a flammable liquid, that is used either to start or spread a fire more quickly.

Acrylic sealant is a synthetic, water-based ingredient made from acrylic resins, used for caulking, jointing and filling cracks and gaps.

Active Fire Protection (AFP) is a group of systems that require special energisation or a command signal to operate, and includes: Detection systems, Alarm Systems, Sprinkler/ water mist systems, Other fire suppression systems, e.g. gaseous, and Smoke control systems.

Many active systems such as a fire alarm will be actuated by a signal in response to the triggering of a detector responding to heat, smoke, CO etc. within its proximity. Alternatively, or in addition these systems will usually be operable by manual triggering, e.g. from a control room or ‘break glass’ box.

Other active systems, such as powder, gas or water filled extinguishers may also be activated via a detector system, or operated manually via a portable hand held device. Fixed sprinkler systems are designed to activate when the temperature around the sprinkler head becomes high enough to activate the sprinkler in question.

Other active fire protection measures include systems such as fire hoses and fire fighting risers, whilst in some instances active and passive measures may combine to form a fire fire protection solution, for example, the use of smoke/ fire detector to instigate the closure of a fire door or the deployment of a smoke ventilation system.

As assessment specifically written for a particular set of circumstances or construction project.

Some penetration seal products may have test evidence created by ad hoc testing to BS476: 20. The testing is deemed ad hoc because the British Standard BS476:20 does not specifically deal with penetration seals.

Air Transfer Grilles are fitted into walls and some doors; and ductwork to keep fresh air circulating. In a fire, intumescent grilles expand to form a solid block that stops fire spreading.

The annulus, or annular space, is the space between a penetrating service and whatever surrounds it, such as the sides of an opening or a sleeve, as the case may be. Sometimes an annulus can be “offset”, meaning that the penetrating service is not centred.

If the firestop was tested only to a perfectly centred opening, an offset may disqualify it for use in the field. In practical terms, an offset penetrating service or annulus may very well present an added degree of difficulty for passing the fire test.

A metallic sleeve as well as a metallic penetrating service will conduct heat through the firestop. Insulation on the bottom of floor systems or in the middle of wall systems, as is the case with caulking or paint based (soft) systems, will encourage more heat to travel through the sleeve and the penetrating service, which can put more stress on the seal on the unexposed side. In the case of a thin (below 4″) firestop mortar, there is also more potential hazard from tight annular spacing because metal expands during the fire, thus squeezing the firestop – only to rapidly shrink when hit with the hose-stream test, which can let water through, thus failing the H rating in Canada or the entire rating in the US, where hose-stream testing is mandatory.

Such a failure may no longer be visible once the test assembly has reached ambient temperatures again. For all these considerations, the annular space is a critical aspect of field approvals.

An opening, hole, gap or space through which light travels.

Government Building regulations for fire safety in residential homes, including new and existing dwellings, flats, residential accommodation, schools, colleges and offices.

A means of automatically detecting the products of a fire and sending a signal to a fire warning system.

Service penetration seals are fire tested to the BS EN 1366-3 test standard. BS EN 1366-3 outlines a method of testing and criteria, including application rules, to assess whether a penetration seal can preserve the fire resistance of a separating element where it has been penetrated by a service.

The purpose of BS EN 1366-3 is to assess:
- The effect of such penetrations on the integrity and insulation performance of the separating element concerned
- The integrity and insulation performance of the penetration seal
- The insulation performance of the penetrating service or services, and where necessary, the integrity failure of a service.

The BS EN 1366-3 test is not intended to supply any information on the ability of the penetration seal to withstand stress caused by any movements or displacements of the penetrating services. Another scenario that cannot be assessed with this test is the risk of fire spreading downwards caused by burning material that drips through a pipe to the floors below.

As a manufacturer, this is the standard that we follow at Quelfire when testing our service penetration systems for fire. The full standard can be purchased on the BSI Online Shop.

A sample defining the detailing and quality of a penetration seal.

A seal that closes the aperture in a fire-resistant wall in order to maintain the wall’s ability to resist fire for a specific time. This is without incorporating penetrating services.

A flat panel, manufactured from gypsum, fibre gypsum, GRG, cement or calcium silicate.

The body responsible for enforcing building regulations on a project and assisting with compliance by given feedback on plans and providing site inspections This may be a local authority building control officer or an approved inspector.

Government Building regulations for fire safety in residential homes, including new and existing dwellings, flats, residential accommodation, schools, colleges and offices.

A dividing wall or barrier between separate compartments.

Unit of bus bar trunking system complete with bus bars, their supports and insulation, external enclosure and any fixing and connection means to other units, with or without tap-off facilities.

A strip or bar of rigid metal that conducts electricity, either as a single element or within a Bus bar trunking unit.

A term used in conjunction with Intumescent Sealant and Fire Batt. Example Intumescent sealant buttered to all exposed mineral wool edges of the Fire Batt.

Cross-laminated timber (CLT) is a wood panel product made from gluing together layers of solid-sawn lumber, i.e., lumber cut from a single log. Each layer of boards is usually oriented perpendicular to adjacent layers and glued on the wide faces of each board, usually in a symmetric way so that the outer layers have the same orientation.

An odd number of layers is most common, but there are configurations with even numbers as well (which are then arranged to give a symmetric configuration).

Regular timber is an anisotropic material, meaning that the physical properties change depending on the direction at which the force is applied. By gluing layers of wood at right angles, the panel can achieve better structural rigidity in both directions.

It is like plywood but with distinctively thicker laminations or lamellae.

COSHH stands for the Control of Substances Hazardous to Health Regulations. These Regulations require employers to control exposure to hazardous substances to prevent ill health.

Hazardous substances include: certain chemicals, bacteria and other microorganisms, certain dusts, any other substance which has comparable health effects. To comply with the Regulations the employer must: assess the risks to health arising from hazardous substances created by the work activity, and decide what precautions are needed to prevent or adequately control exposure.

The Regulations have a hierarchy of control measures which must be followed. If it is possible the activity or process must be changed so that the hazardous substance is not used or generated, or a safer alternative should be used. Only if prevention is not reasonably practicable should the exposure be controlled by methods such as enclosure and ventilation.

The last control measure should be the use of personal protective equipment. The employer must make sure that the control measures are properly used and maintained. If necessary, they must monitor exposure and under some circumstance‚ health surveillance must be provided. Employees must also be properly informed, trained and supervised. Just having safety data sheets on file is not sufficient to comply with the requirements.

An activity that professionals engage in to develop and enhance their abilities. It enables learning to become conscious and proactive, rather than passive and reactive. CPD combines different methodologies to learning, such as training workshops, conferences and events, e-learning programs, best practice techniques and ideas sharing, all focused for an individual to improve and have effective professional development.

Chlorinated polyvinyl chloride (CPVC) is a thermoplastic produced by chlorination of polyvinyl chloride (PVC) resin, which is significantly more flexible and can withstand higher temperatures than standard PVC. Uses include hot and cold-water delivery pipes and industrial liquid handling. CPVC, as PVC, is deemed safe for the transport and use of potable water, potable meaning water used for drinking, cooking, and bathing.

A component of a cable installation system for the continuous support of cables, such as cable ladders, cable trays, or cable baskets.

Application of fire retardants, which are either endothermic or intumescent, to reduce flame spread and smoke development of combustible cable-jacketing.

Fire Collars that are fixed to form work prior to the pouring of a concrete slab.

A construction, other than a smoke curtain, provided to close a concealed space against penetration of smoke or flame, or provided to restrict the movement of smoke or flame within such a space.

A declaration of the conformity with the type of approval of EC. The purpose of this document is to ensure the free movement of goods within the European Union, specifically for those goods that are subject to homologation and registration.

Partially burn to blacken the surface.

Boards used for the same purpose and in the same applications as spray fireproofing. Materials for such cladding include perlite, vermiculite, calcium silicate, gypsum, intumescent epoxy, Durasteel (cellulose-fibre reinforced concrete and punched sheet-metal bonded composite panels), MicroTherm.

A performance level assigned to a product following a test to a European Standard.

Closures (fire dampers) Sometimes firestops are treated in building codes identically to closures. Canada de-rates closures, where, for instance a 2-hour closure is acceptable for use in a 3-hour fire separation, so long as the fire separation is not an occupancy separation or firewall. The lowered rating is then referred to as a fire protection rating, both for firestops, unless they contain plastic pipes and regular closures.

Smoke at ambient temperatures.

A pipe closure device incorporating an outer casing which acts as a restraint for an intumescent material, enabling the collar to be either surface fixed to the fire separating element or incorporated within it.

Able to catch fire and burn easily.

A fire-resisting wall or floor that provide a barrier and separate one fire compartment from another.

Compartmentation is an important element of passive fire protection and is achieved by dividing the premises into fire compartments through the use of fire doors, floors and walls of fire-resisting construction, cavity barriers within roof voids and fire stopping to services that penetrate through these dividing elements.

Fire Protection Compound is intended for use as a gap filling material where cables, ducts or pipework services penetrate fire compartment floors and walls. See Also Mortar, Fire Protection Compound, and QF2.

A metal or plastic casing designed to accommodate cables, normally circular in section.

Dampers are moveable metal plates in a flue or chimney, used to regulate the draught and control the rate of combustion.

Deflection is the amount an element or structure bends or sags when a load is applied. Allowable deflection is generally expressed as a fraction of the span, in inches.

All structural elements will deflect or flex under load; however, the amount of flex depends on the magnitude of the load applied and the span and stiffness of the structural elements. Typically for better performing floors, minimal deflection is required.

Ducts are conduits or passages used in heating, ventilation, and air conditioning (HVAC) to deliver and remove air. The needed airflows include, for example, supply air, return air, and exhaust air. Ducts commonly also deliver ventilation air as part of the supply air. As such, air ducts are one method of ensuring acceptable indoor air quality as well as thermal comfort. A duct system is also called ductwork. Planning (laying out), sizing, optimising, detailing, and finding the pressure losses through a duct system is called duct design.

The durability of reactive materials may change significantly when exposed to specific weathering conditions. This change may result in a product not achieving the expected performance in the event of a fire.

Where a product is not subject to further processing (e.g. external protection or encapsulation) to achieve its final form, it shall be tested for durability in accordance with the guidance in this document. Where a product is subject to further processing, such as encapsulation in waterproof casings, the durability tests should be conducted in accordance with the product specification.

The following types of final intended use conditions are considered to be relevant for reactive materials, components and products and should be tested correspondingly:

Type X: intended for use at conditions exposed to weathering

Type Y1: intended for use at temperatures below 0°C with exposure to UV but no exposure to rain

Type Y2: intended for use at temperatures below 0°C, but with no exposure to rain nor UV

Type Z1: intended for use at internal conditions with high humidity, excluding temperatures below 0°C

Type Z2: intended for use at internal conditions with humidity classes other than Z1, excluding temperatures below 0°C.

Note: Materials that meet requirements for type X, meet the requirements for all other types.

In summary, products that are going to be exposed to external weathering conditions such as Cast In Fire Collars should be tested to Type X Durability.

Documentation of the methods and criteria accepted in European Organisation for technical Assessment (EOTA) as being applicable for the assessment of the performance of a construction product in relation to its essential characteristics.

The European Technical Assessment is a document providing information about the performance of a construction product to be declared in relation to its essential characteristics. The ETA provides a way for the manufacturer to CE Mark a product.

Any material exhibiting elastic or rubber-like properties. Elastomeric materials are generally measured in material type, compound, and durometer (the hardness of the material).

Any material exhibiting elastic or rubber-like properties. Elastomeric materials are generally measured in material type, compound, and durometer (the hardness of the material).

If something is endothermic it absorbs heat, preventing the temperature from rising on the other side of the barrier.

An expansion joint is a created joint between two sections of a concrete floor slab, which gets narrower when the panels of the slab expand, due to an increase in ambient temperature.

Fire Barriers are a fire-resistant barrier used to prevent the spread of fire for a prescribed period.

A dense mineral wool board, but light weight in comparison to Fire boards. Typically used for sealing penetrations.

A product that is used to stop fire and typically protect structural steel and duct work. This product varies in weight, size and thickness dependent on which supplier it comes from. The thickness also effects the level of Fire Rating for the asset it is protecting.

Fire caulk is designed to expand and fill that void of the melted pipe during a fire. Most fire caulks begin to start activating at temperatures greater than 200 degrees Fahrenheit. Since more lives are lost by the smoke of fires, fire caulk is also designed to help keep smoke from spreading.

Fire collars are designed to maintain fire resistance levels by surrounding pipes and other penetrations with intumescent compounds that expand throughout the fire, preventing flames and hot gases passing into other compartments.

Building compartmentation is an important element of passive fire protection. The purpose of Fire Compartmentation is to contain the fire to its area of origin for as long as possible. This is to allow time for occupants to safely evacuate the building, increase the time fire and rescue services have to arrive and start tackling the fire, and to limit the damage caused to a building and its contents.

Fire Compartmentation is achieved by dividing the premises into areas of manageable risk using fire-resistant barriers within a building such as, masonry and fire rated plasterboard walls, concrete and fire-resistant ceilings and floors.

However, it will be unlikely that your compartmentation will remain a solid box. This is because for inhabitants to live in these areas the fire-resistant barriers will require openings thus, voiding the fire resistance rating of the fire separating element. Openings can include doors, windows, and service penetrations such as cables and pipes. Every penetration that breaks the compartmentation line must be adequately fire stopped to reinstate the required fire resistance rating.

To ensure you can reinstate the compartmentation of the fire separating element, you must consider all factors of the application including the actual service penetration types and the supporting construction itself. Certain applications can be particularly challenging to reinstate the required fire rating. This could be due to the supporting construction itself having insufficient test evidence or for example, large uninsulated metal pipes which can relatively easily provide an integrity fire resistance rating but generally are much more challenging to provide an insulation fire rating.

Fire covers are designed for stopping fires in electric light units in fire rated suspended ceilings. In the event of a fire, the cover expands internally to fill all the available space with a fire resistant, highly insulating char.

A fire curtain is a specially constructed curtain that descends from the ceiling to block an opening and stop fire and smoke spreading between two areas.

In larger structures, several fire curtains are used which divide the building into fire compartments when there is a fire. A fire curtain is similar to a metal roller shutter in that it descends vertically as it un-rolls from a top box, however because a fire curtain is made of a woven fibre glass material, it is much more flexible and compact. This means a curtain can be more closely fitted within a space and therefore provides much better compartmentation.

The compact construction of fire curtains makes them an ideal choice for lobbies, hatches and stairwells where there is limited space. When included in the design stage of a building, they can be recessed into walls and ceilings leaving a thin slit as the only indication that the curtain is there.

There are several types of fire curtain:

Automatic Fire curtains: most non-static fire curtains are in fact automatic. They are linked to the fire alarm system, so they automatically descend when there is a fire.

Static Fire Curtains: also called fixed fire curtains, these curtains are permanently in place and are used to provide compartmentation in open spaces such as warehouses or lofts.

Insulated Fire Curtains: these curtains provide extra insulation and allow people to pass by much closer to the curtain without being affected by the heat of the fire on the other side.

Devices designed to impede the spread of fire through walls, floors and partitions. Fire dampers are installed in the ducts of heating, ventilation and air conditioning systems which penetrate fire-resistant constructions. When a rise in temperature occurs, the fire damper closes, usually activated by a thermal element which melts at temperatures higher than ambient but low enough to indicate the presence of a fire, allowing springs to close the damper blades. Fire dampers can also close following receipt of an electrical signal from a fire alarm system utilising detector remote from the damper, indicating the sensing of heat or smoke in the building occupied spaces or in the HVAC duct system.

A Fire Door is intended to restrict the passage of a fire when it is closed. It can also be designed to restrict the spread of any smoke generated by the fire. Fire doors and their frames and fixtures are designed to perform in a predictable way so that they will fail after a given period of time allowing occupants to escape through an alternative route.

A fire engineer, by education, training and experience understands the following:

- The nature and characteristics of fire,
- The mechanisms of fire spread,
- The control of fire and the associated products of combustion,
- How fires originate spread within and outside buildings/structures can be detected, controlled, and/or extinguished,
- Anticipates the behaviour of materials, structures, machines, apparatus, and processes as related to the protection of life, property and the environment from fire,
- Understands the interactions and integration of fire safety systems and all other systems in buildings, industrial structures and similar facilities.

A fire Engineer should be able to make use of all the above and any other required knowledge to undertake the practice of fire engineering.

Fire Engineering is the application of scientific and engineering principles, rules [Codes], and expert judgement, based on an understanding of the phenomena and effects of fire and of the reaction and behaviour of people to fire, to protect people, property and the environment from the destructive effects of fire.

These objectives will be achieved by a variety of means including such activities as: the assessment of the hazards and risks of fire and its effects, the mitigation of potential fire damage by proper design, construction, arrangement, and use of buildings, materials, structures, industrial processes, transportation systems and similar, the appropriate level of evaluation for the optimum preventive and protective measures necessary to limit the consequences of fire, the design, installation, maintenance and/or development of fire detection, fire suppression, fire control and fire related communication systems and equipment, the direction and control of appropriate equipment and manpower in the strategy and function of firefighting and rescue operations, Post-fire investigation and analysis, evaluation and feedback.

A fire insulation rating is a measure of time that a specific component or system can withstand the heat generated from a fire and prevent it from breaching the building's compartmentation.

In a BS EN1366-3 test, there should be no individual hotspots of 180°C, or an average increase of 140°C, on the construction, services, or seal on the non-fire side. For context, it is worth understanding that inside the furnace (fire side), the temperature can exceed 1000°C.

The letter I is used to measure a fire insulation rating, and the measure is in minutes. For example, EI 30 represents 30 minutes/ half-hour integrity and insulation, and EI 240 represents 240 minutes / 4 hours integrity and insulation.

A fire integrity rating is a measure of time that a specific component or system can withstand and prevent the physical passage of fire breaching the building’s compartmentation.

Fire integrity is measured by both observation and through the use of a ‘cotton wool pad test.' Put simply, a cotton wool pad is strategically positioned for a certain period of time and if it ignites then the product or system is deemed to have failed.

The letter E is used to measure an integrity rating and the measure is in minutes. For example, E30 represents 30 minutes/ half-hour and E240 represents 240 minutes / 4 hours.

A fire-resistant interior wall intended to prevent the spread of fire or to provide protection to occupants during the evacuation process of a burning building.

Fire Protection Compound is intended for use as a gap filling material where cables, ducts or pipework services penetrate fire compartment floors and walls. See Also Compound, Mortar, and QF2.

Adhesive pads and linings for use with a wide range of electrical boxes.

Means the ability of a building component to resist a fully developed fire, while still performing its function for a graded period of minutes.

Ability of a component or construction of a building to meet for a stated period of time some or all of the appropriate criteria of relevant standards. See BS EN 1363-1, BS 476-7 and associated standards for further information.

Used on structural steel, mechanical ductwork and dry walls can be achieved with several products e.g. 16mm fire check plaster and fire rated boards installed in accordance with its tested system to achieve compliance.

Often called fire retardants, or mistakenly called “fireproof” paints, intumescent paints refer to that class of designed paints which swell and form a protective “char” as a result of extreme heat exposure – such as a fire – increasing in volume.

Fire-resistant glass is glass using multi-layer intumescent technology or wire mesh embedded within the glass may be used in the fabrication of fire-resistance rated windows in walls or fire doors.

A Fire Risk Assessment is an organised and methodical look at your premises, the activities carried on there and the likelihood that a fire could start and cause harm to those in and around the premises.

The aims of the fire risk assessment are:

- To identify the fire hazards,
- To reduce the risk of those hazards causing harm to as low as reasonably practicable,
- To decide what physical fire precautions and management arrangements are necessary to ensure the safety of people in your premises if a fire does start.

The term ‘where necessary’ (see Regulatory Reform Section Above) is used in the Order, therefore when deciding what fire precautions and management arrangements are necessary you will need to take account of this definition.

The terms ‘hazard’ and ‘risk’ are used throughout this guide and it is important that you have a clear understanding of how these should be used.

Hazard: anything that has the potential to cause harm.
Risk: the chance of that harm occurring.

If your organisation employs five or more people or your premises are licensed or an alteration notice requiring it is in force, then the significant findings of the Fire Risk Assessment, the actions to be taken as a result of the assessment and details of anyone especially at risk must be recorded. You will probably find it helpful to keep a record of the significant findings of your fire risk assessment even if you are not required to do so.

The Regulatory Reform (Fire Safety) Order 2005 covers general fire precautions and other fire safety duties which are needed to protect ‘relevant persons’ in case of fire.

The order requires fire precautions to be put in place ‘where necessary’ and to the extent that it is reasonable and practicable. Responsibility for complying with the Order rests with the ‘responsible person’. In a workplace this is principally the employer and then any other person who may have control of any part of the premises, e.g. the occupier or owner. In all other premises the person or people in control will be responsible.

The responsible person must carry out a fire risk assessment which must focus on the safety in case of fire of all relevant persons. It should pay attention to those at special risk and must include consideration of any dangerous substance likely to be on the premises. The risk assessment will help identify risks that can be removed or reduced and to decide the extent of the general fire precautions necessary.

If 5 or more are employed (or a license is in force for the premises) then the significant findings of the risk assessment must be recorded.

Fire sealants and gap fillers expand when heated at high temperatures blocking gaps and slowing down the spread of fire.

A compartment wall, compartment floor or construction that encloses a protected escape route and/ or a place of special fire hazard.

Fire sleeves are designed to fill or seal an aperture created by pipes or cables passing through a fire-rated wall or ceiling by expanding to fill the available space, preventing the passage of fire and smoke to the adjacent compartment.

Cavity fire barrier manufactured from rock fibre mineral wool insulation for masonry construction.

A seal provided to close an imperfection of fit or design tolerance between elements or components, to restrict the passage of fire and smoke.

Is a fire protection system made of various components used to seal openings, control joints in fire resistant walls, floors, or assemblies.

Also called the Combustion Triangle, this is a simple model for understanding the necessary ingredients for most fires. The triangle illustrates the three elements a fire needs to ignite: heat, fuel, and an oxidising agent (usually oxygen).

A plasterboard with fire-resistant additives.

Firewalls not only have a rating, but they are also designed to sub-divide buildings such that if collapse occurs on one side, this will not affect the other side.

Drylining horizontal or vertical supporting construction consisting of studs or joists, including linings and optional insulation.

Flexible ducts (also known as flex) are typically made of flexible plastic over a metal wire coil to shape a tube. They have a variety of configurations. In the United States, the insulation is usually glass wool, but other markets such as Australia, use both polyester fibre and glass wool for thermal insulation. A protective layer surrounds the insulation, and is usually composed of polyethylene or metalised PET. It is commonly sold as boxes containing 25′ of duct compressed into a 5′ length.

It is available in diameters ranging from as small as 4″ to as big as 18″, but the most commonly used are even sizes ranging from 6″ to 12″. Flexible duct is very convenient for attaching supply air outlets to the rigid ductwork. It is commonly attached with long zip ties or metal band claps. However, the pressure loss is higher than for most other types of ducts.

As such, designers and installers attempt to keep their installed lengths (runs) short, e.g. less than 15 feet or so, and try to minimize turns. Kinks in flexible ducting must be avoided.

Some flexible duct markets prefer to avoid using flexible duct on the return air portions of HVAC systems, however flexible duct can tolerate moderate negative pressures.

A metal stud drylined partition is defined as a flexible partition in a fire test.

Flexible wall is a vertical supporting construction consisting of studs or joists, including linings and optional insulation. The term is commonly used when referring to fire-rated plasterboard partition systems.

This type of wall is usually non-load bearing and its fire resistance performance has been determined according to the appropriate European standards. The reaction to fire performance of the exposed surfaces is also determined by the appropriate fire test standards. Requirements to determine the fire resistance and the reaction to fire performance of a partition are stated in current Building Regulations.

When a fire has become fully developed it attacks the structure of the compartment and attempts to spread beyond the origin. A fire-rated partition prevents this by creating a structure that does not collapse and contains the fire for a given period of time. It is necessary to determine the fire resistance of the partition by assessing its behaviour when subjected to defined heating and pressure conditions that can be encountered in a fully developed fire.

Fire resistance tests employ a standard temperature/time curve and pressure distribution for this purpose with the resistance of such partitions ranging from 30 to 240 minutes or more.

A formed letterbox is an aperture that has been physically constructed within a wall construction using stud and boards of the same specification as the wall itself. Otherwise known as a framed and lined letterbox, a stud is used to create a frame, and then the inside of the aperture is lined with plasterboard. The fire stop seal is then installed inside the opening.

If the aperture in the wall has been roughly cut out and not formed (framed and lined), then it may be necessary to fit the fire batt fire seal to the outside of the wall. This is what’s known as a pattress-fit or face-fix batt system.

In any case, apertures should be created in accordance with the wall manufacturer’s recommendations based on their tested scope of application.

Galvanized mild steel is the standard and most common material used in fabricating ductwork because the zinc coating of this metal prevents rusting and avoids the cost of painting.

For insulation purposes, metal ducts are typically lined with faced fiberglass blankets (duct liner) or wrapped externally with fiberglass blankets (duct wrap).

When necessary, a double-walled duct is used. This will usually have an inner perforated liner, then a 1–2" layer of fiberglass insulation contained inside an outer solid pipe.

Rectangular ductwork commonly is fabricated to suit by specialized metal shops. For ease of handling, it most often comes in 4' sections (or joints).

Round duct is made using a continuous spiral forming machine, which can produce round duct in nearly any diameter when using the right forming die, and to any length to suit. However, the most common stock sizes range evenly from 4" to 24", with 6"-12" being the most commonly used.

Stock pipe is usually sold in 10' joints. There are also 5' joints of the non-spiral type of pipe available, which is commonly used in residential applications.

HDPE pipe is a type of flexible plastic pipe used for fluid and gas transfer and is often used to replace ageing concrete or steel mains pipelines. Made from the thermoplastic HDPE (high-density polyethylene), its high level of impermeability and strong molecular bond make it suitable for high-pressure pipelines. HDPE pipe is used worldwide for various applications, including water mains, gas mains, sewer mains, slurry transfer lines, rural irrigation systems, fire system supply lines, electrical and communications conduits, and stormwater and drainage pipes.

HPE Sealant is a water-based, acrylic sealant utilising a reactive formula with intumescent properties to restore the fire resistance performance of wall and floor constructions where penetrations of single or multiple services are present. HPE Sealant expands upon contact with heat, and the high-pressure reactive process ensures that the material will expand to fill any void around penetration services.

High Pressure Expansion

Heating, ventilation, and air conditioning is the technology of indoor and vehicular environmental comfort. Its goal is to provide thermal comfort and acceptable indoor air quality.

HVAC system design is a subdiscipline of mechanical engineering, based on the principles of thermodynamics, fluid mechanics and heat transfer. “Refrigeration” is sometimes added to the field’s abbreviation, as HVAC&R or HVACR or “ventilation” is dropped, as in HACR (as in the designation of HACR-rated circuit breakers).

HVAC is an important part of residential structures such as single-family homes, apartment buildings, hotels and senior living facilities, medium to large industrial and office buildings such as skyscrapers and hospitals, vehicles such as cars, trains, airplanes, ships and submarines, and in marine environments, where safe and healthy building conditions are regulated with respect to temperature and humidity, using fresh air from outdoors.

Ventilating or ventilation (the “V” in HVAC) is the process of exchanging or replacing air in any space to provide high indoor air quality which involves temperature control, oxygen replenishment, and removal of moisture, odours, smoke, heat, dust, airborne bacteria, carbon dioxide, and other gases.

Ventilation removes unpleasant smells and excessive moisture, introduces outside air, keeps interior building air circulating, and prevents stagnation of the interior air. Ventilation includes both the exchange of air to the outside as well as circulation of air within the building.

It is one of the most important factors for maintaining acceptable indoor air quality in buildings. Methods for ventilating a building may be divided into mechanical/forced and natural types.

Harder chars are produced with sodium silicates and graphite. These products are suitable for use in service penetration firestop seals, as well as exterior steel fireproofing. In those applications, it is necessary to produce a more substantial char capable of exerting quantifiable expansion pressure.

In the case of a service penetration firestop seal, a burning plastic pipe, for example, that is melting must be squeezed together and shut off, so that there is no opening for fire to propagate through the fire-resistance-rated wall or floor assembly.

The expanding intumescent will push against the softening plastic and close any void that forms, creating a protective char that prevents the fire from passing through the penetrated fire-separating element.

Generally, liquids with a flashpoint of below 21 °C. The Chemicals Hazard Information and Packaging for Supply Regulations 2002 (CHIP) gives more guidance.

Insulated Fire Sleeves possess a combination of stone wool and graphite intumescent to create a thermal and fire insulation solution. When exposed to fire, the insulated fire sleeves expand and seal the gaps between surrounding pipework and construction, and will continue to close the gap as plastic pipes melt or soften.

Insulation, represented by the letter I, is a measurement of time giving an indication of how long a component can withstand the heat generated from a fire and prevent it from breaching the building’s compartmentation. During the fire, the construction on the non-heated side typically should not exceed +180 °C in a BSEN1366-3 test.

Integrity is one of the readings that the fire-resistant components of the building or structure have. This reading highlights the time that the component can withstand and prevent fire as well as smoke from breaching the building's compartmentation. The letter denoting the integrity feature is “E”. Integrity (E) refers to the ability of a component or construction to maintain the integrity of the element on one side only, without allowing flames to penetrate and spread to the non-heated side.

Firestop pillows are passive fire protection items, used for firestopping holes in wall or floor assemblies required to have a fire-resistance rating. Firestop pillows are used in openings that require frequent access (e.g., cable changes), requiring the removal of the firestopping and resealing after the changes are completed. The intumescent resins in batt-based firestop pillows contains hydrates, or chemically bound water. On the fire side, the plastic bag burns off exposing the intumescent to the fire, which releases the water in the form of vapour or steam. The steam rises and hits the plastic bag interior on the unexposed side, where it condenses back to water, and runs back down to cool the installation below. Batt-based pillows are held in place by compressing them, allowing friction to restrain them. If replaced enough times, the pillows will retain a permanent compression, requiring their replacement with new components.

A seal used to impede the flow of heat, flame or gases, which only becomes active when subjected to elevated temperature. Intumescent seals are components which expand, helping to fill gaps and voids, when subjected to heat more than ambient temperatures. See: BS 8214:2008.

An intumescent strip (or intumescent seal) is a piece of material that, when exposed to heat, expands, closing any gaps to stop the fire spreading for a period of time. Intumescent strips typically offer either 30 or 60 minutes of fire resistance.

An alternative solution to pipe collars. Manufactured from layers of a graphite-based intumescent sheet, which is then encased in a polythene sheath. The product is wrapped around the outside of the pipework and fixed in place with self-adhesive strips. Should a fire occur, the Intumescent Pipe Wrap will expand to fill any void that is left behind by burnt-out plastic, preventing the passage of flames and smoke.

Intumescent is a substance that will expand because of heat exposure (generally fire), increasing in volume whilst simultaneously decreasing in density.

By swelling, the substance forms a char which seeks to either encase the material it’s applied to, thus protecting it from damage, or expand to fill any voids with a protective char, preventing the passage of fire through a fire-separating element.

Intumescent can be broken down into types:
- Soft char
- Hard char

A permanent marking next to a penetration providing information about the penetration seal.

A letterbox opening is a prepared opening in a separating element wall/ floor designed for services to pass through. It is a type of builder’s hole.

Linear joint seals are passive fire protection systems designed to maintain the required building fire resistance across a separating element, plus, if and where relevant, to accommodate a defined degree of movement. Linear joint seals can be found in walls, floors, and in so-called head-of-wall applications – joints between walls and ceilings or walls and floors.

Linear Joints for the UK and Europe are typically tested to the BS EN1366-4 fire-resistance test standard.

A load-bearing floor is a floor that bears weight resting upon it.

A load-bearing wall or bearing wall is a wall that is an active structural element of a building, that is, it bears the weight of the elements above wall, resting upon it by conducting its weight to a foundation structure. The materials most often used to construct load-bearing walls in large buildings are concrete, block, or brick.

Safety data sheets provide information on chemical products that help users of those chemicals to make a risk assessment. They describe the hazards the chemical presents, and give information on handling, storage and emergency measures in case of accident.

A hole in one side of a fire-rated wall or floor for a single surface-barrier penetration, such as an electrical socket.

Mineral wool is any fibrous material formed by spinning or drawing molten mineral or rock materials such as slag and ceramics. Applications of mineral wool include thermal insulation (as both structural insulation and pipe insulation, though it is not as fire-resistant as high-temperature insulation wool), filtration, soundproofing, and hydroponic growth medium.

A mixed or multiservice penetration seal is where more than one of the same or different type of services penetrate the one aperture. For instance, a letterbox aperture above a flat entrance door containing a sprinkler pipe, cable tray, hot and cold water feeds and a plastic ventilation duct.

Multiservice penetration seals typically require a Fire Batt or Fire Protection Compound to complete the larger oversized aperture. Services are then sealed with additional fire stop seals that are fitted within, or to, the overall seal.

In accordance with BSEN1366-3, the fire resistance test standard, there must be a minimum of 100mm between penetration seals unless tested otherwise.

Whilst multiple services can penetrate the fire batt seal, the spacing requirements between the individual seals within the overall seal must be observed.

Therefore, spacing requirements could vary between different service types and may require 100mm between the seals. This is unless they are tested at less, which could be 50mm or even 0mm between services of the same type.

There is also a need to allow for space between the seals and the edge of the apertures. It is important to understand that the spacing requirement is between the service seals and not between the services themselves, so the seal size needs to be considered.

Intended for use as a gap-filling material where cables, ducts, or pipework services penetrate fire compartment floors and walls.

There can be a range of factors that cause movement within a building, including thermal, seismic, and subsidence. This is most apparent in high-rise buildings. Without considering the building's movement, it could lead to specific systems failing and compartmentation being compromised.

MLCP is often perceived to be comparable to plastic-only pipe, commonly used in DIY projects. But it is a halfway house between polybutylene pipework and copper piping, consisting of a plastic pipe (PE-Xb) with an internal aluminium layer that offers rigidity, form retention, and a solid oxygen barrier to prevent internal corrosion of heating system components. MLCP is an alternative piping solution to copper.

Material that does not burn if exposed to fire.

Barriers designated as occupancy separations are intended to segregate parts of buildings, where different uses are on each side; for instance, apartments on one side and stores on the other side of the occupancy separation.

Fire doors and windows are installed in an opening of a fire barrier to maintain its fire resistance. Fire-rated glazing and framing are tested as a complete assembly to maintain the protection of the fire barrier. Additionally, fire and smoke dampers (often used in duct systems) are considered “opening protection” and complete the fire barrier where air ducts penetrate fire-rated and/or smoke-resistant assemblies.

Polyethylene (PE) pipe is the most often used plastic pipe for underground utility construction. PE pipe is used for a variety of applications, including the distribution of pressurised natural gas, pipelines carrying petroleum and petroleum products, and underground loops for geothermal heating and cooling systems. It is also used for the distribution of compressed gases and air, potable water mains and service lines, as well as sanitary and storm sewer systems. Corrugated PE pipe is used for storm sewers and highway drainage.

Polypropylene (PP) is the lightest-weight piping material with very good chemical resistance, even to many organic solvents. It is used extensively for HVAC applications and is available in two classifications, with Type I being the most common. Type I has better rigidity and strength but lower impact resistance than Type II, which has improved toughness over Type I material. In chemical drainage applications, heat stabilizers and flame-retardant additives are added to PP to retard flammability and thermal aging.

PP is also used in many more corrosive and higher temperature applications (180°F) than PVC. Like purple PVC and CPVC, purple PP is being used for non-potable applications. The primary method of joining PP piping systems is through heat fusion, although mechanical joints can also be used. PP pipe is available in standard 20’ lengths in sizes ranging from ½" to 40".

To accommodate different working pressures, PP is available in both schedule 80 and schedule 40. Typical applications include chemical drainage systems, industrial processes, high-purity water systems, hot and cold water distribution, and gravity sewer systems.

PVC low-profile ducting has been developed as a cost-effective alternative to steel low-profile ducting. Low-profile ducting has been used extensively in apartment and hotel ventilation since 2005. The growth of low-profile ducting has grown significantly due to the reduction of available space in ceiling cavities to reduce cost. Since the Grenfell Tower fire in 2017, there has been a rise in the discovery of non-compliant building materials; many PVC low-profile ducting manufacturers have struggled to gain or maintain compliance, and some building projects have had to resort back to using the more expensive steel option.

PVC (polyvinyl chloride) is a thermoplastic material, which comprises 57% chlorine (obtained from industrial grade salt) and 43% carbon (obtained mainly from oil/gas through ethylene). This flexible material is commonly used as a replacement for copper and aluminium pipes in several areas. PVC Pipes are used for plumbing and drainage, replacing metal piping. PVC is also used as insulation on electrical cables, such as those used in teck. For this purpose, PVC needs to be plasticised.

Flexible PVC-coated wire and cable for electrical use has traditionally been stabilised with lead, but these are being replaced with calcium-zinc-based systems. In a fire, PVC-coated wires can produce hydrogen chloride fumes; the chlorine serves to scavenge free radicals and is the source of the material's fire-retardant properties. While hydrogen chloride fumes can also pose a health hazard, they dissolve in moisture and break down onto surfaces, particularly in areas where the air is cool enough to breathe and is not available for inhalation.

Frequently, in applications where smoke is a major hazard (notably in tunnels and communal areas), PVC-free cable insulation is preferred, such as low-smoke, zero-halogen (LSZH) insulation. Plastic pipes exposed to fire will react differently according to the type of plastic they are made from. Some will soften and then char as the fire progresses; others will soften and melt. If not properly fire-stopped, these pipes may burn out, leaving a passage for fire to spread into adjoining rooms and allowing a fire to quickly spread.

Fire collars and fire sleeves with intumescent materials are typically used to seal the pipe shut, completely preventing the fire from passing through. Because different types of plastic can react to fire in different ways, you must ensure the fire collar you choose is tested and approved for the type of plastic or make of pipe you are using.

A structure dividing a space into two parts, especially a light interior wall.

Passive Fire Protection systems are solutions that seek to contain the fire by delaying its growth using fire-rated partitions and doors to prevent the fire and smoke from spreading from one compartment to another, and to delay the collapse of the building structure.

Passive Fire Protection systems include:

Fire protection to the structural frame of the building, Fire-resisting doors and fire door furniture, Fire shutters, Compartment walls and floors, Fire-resisting walls and partitions, Suspended ceilings, Fire-resisting glazing, Fire doors and hardware, Industrial fire shutters and curtains, Firefighting shafts and stairwells, Fire-resisting dampers (mechanical or intumescent) used in horizontal or vertical air distribution ducts, Fire-resisting ductwork, Fire-resisting service ducts and shafts, Linear gap seals, Penetration seals for pipes, cables and other services, Cavity barriers, Fire-resisting air transfer grilles (mechanical or intumescent), The building envelope, e.g., fire-resisting external walls, curtain walls etc., Reaction to fire coatings, Hydrocarbon structural fire protection systems.

A product or system that provides protection to the building and occupants without further change or requirement for activation or motion.

Penetration seal is a system used to maintain the fire resistance of a separating element at the position where services pass through or where there is provision for services to pass through a separating element.

A penetration seal system is a highly effective form of passive fire protection (PFP). They are used extensively to compartmentalise a building to restrict the spread of fire.

In fire-stopping, a penetration is an opening in a wall or floor assembly required to have a fire rating, for the purpose of accommodating the passage of a mechanical, electrical, or structural penetrant.

A pipe closure device is a reactive device in varying sizes, to seal penetrations, including associated pipe insulation.

A pipe closure device includes an elastomeric sealing ring with a threaded bore that tapers from an outer to an inner end of the sealing ring. A threaded plug having a tapered configuration from an outer to an inner end thereof is threadably receivable in the sealing ring, whereby the sealing ring is expanded and engages the opening in sealing relation. The plug includes a multi-sided boss that is fixedly attached to and extends from its outer end. The sealing ring engages the opening when the plug is inserted into the bore, creating a frictional engagement whereby the sealing ring resists rotation and axial sliding within the opening as the plug is axially advanced into the bore.

The absorption of small, chemically benign molecules that migrate between the macromolecular chains, thus allowing the plastic part to lose stiffness.

Metal decking typically has a ribbed or corrugated profile that is achieved through a process called roll forming. Large sheets of metal are pulled from rolls and led through rolling dies that create the ribbed profile. Metal decking is used for flooring and roofing and for the creation of forms for concrete.

Putty Pads are made from intumescent putty, which is primarily used as a firestopping product.

Any product with a temperature of absolute zero emits energy (heat). This energy reacts with other objects and can cause them to reach a point of combustion.

A cavity fire barrier for rainscreen cladding applications that maintains a ventilated cavity.

A place of reasonable safety in which a disabled person and others who may need assistance may rest or wait for assistance before reaching a place of total safety. It should lead directly to a fire-resisting escape route.

The Regulatory Reform (Fire Safety) Order 2005 places the responsibility on individuals within an organisation to carry out risk assessments to identify, manage, and reduce the risk of fire.

A rigid construction is a high-density constructing element designed from block work, masonry, or concrete, with an overall density ≥850kg/m³ and a thickness appropriate for the expected fire-resistance period. It can also be a low-density constructing element made from aerated concrete block, masonry, or lintels, with an overall density of ≥650kg/m³ and a thickness appropriate for the expected fire-resistance period.

A floor made of aerated concrete slabs, lightweight concrete, or high-density concrete and a thickness appropriate to the required fire-resistance classification.

A wall made of aerated concrete slabs, lightweight concrete, or high-density concrete and a thickness appropriate to the required fire-resistance classification.

Risers are unique fire compartments. Examples include: Electrical, hydraulic, mechanical, plumbing, and communications.

In Scotland, ministers are responsible for making building standards and the associated technical guidance documents. The Building (Scotland) Act 2003 grants these powers. The main purpose of the standards is to ensure the building is safe, efficient, and sustainable. They do not control the building process, but outline the essential standards that must be met during building works or conversions.

The key functions of the building standard system are to: Prepare the building standards and produce guidance on how to attain the standards, assist local authorities in making decisions on compliance, allow relaxations of the standards in exceptional circumstances, maintain a register of approved certifiers, regulate the certification system, regulate the performance of verifiers, and verify crown building work.

There are two technical handbooks which provide guidance on achieving the building standards: the Domestic Handbook and the Non-Domestic Handbook. Certification is an optional scheme for implementing building standards applicable to work that requires a building warrant. It can only be undertaken by a registered, approved certifier of design or construction holding the appropriate designations and employed by an appropriate body of business.

The Building Standards Technical Handbooks provide guidance on achieving the standards set in the Building (Scotland) Regulations 2004.

The Building Standards Technical Handbooks guide the achievement of the standards set in the Building (Scotland) Regulations 2004. This handbook applies to a building warrant submitted on or after 1 October 2019, and to building work that does not require a warrant, commenced from that date.

A fitting provided to close a gap for the purpose of controlling the passage of air, smoke, water, fire, sound, etc.

An approved device that will ensure closing after having been opened.

A mechanical support provided in the form of clips, ties, hangers, or any device designed to carry the load of the penetrating services. The service support construction does not include cable carriers.

There are many different types of services, and each potentially require their own unique fire seal.

For instance, plastic pipes are an obvious different type to an electric cable bundle but there are also more subtle differences which can cause some confusion to those less familiar with the details. A plastic conduit with a cable in it is not the same as a plastic pipe.

Likewise, an insulated copper pipe is very different to a plastic pipe and will require a different type of seal, so it is important to be clear when selecting fire stop seals that you are clear about what it is that you are actually sealing.

An enclosed space extending through one or more stories of a building, connecting vertical openings in successive floors, or floors and roof.

Mineral Wool Shuttering Slab provides a simple means of shuttering to allow the use of fire protection compounds.

A Single Opening is a prepared opening in a separating element wall/floor designed for services to pass through. It is a type of builder’s hole.

Just like it sounds, a single penetration is a single hole for a single service (or group of the same services). For instance, an individual cable (or bundle of cables) passing through a wall.

Single penetrations may also be referred to as a ‘direct-to-wall’ seal or a ‘direct-to-floor’ seal as they often require a single product fixed/sealed directly around the services.

In contrast, a ‘multiservice penetration seal’ is where different types of services penetrate the one aperture. For instance, a letterbox aperture above a flat entrance door maybe containing a sprinkler pipe, cable tray, hot and cold water feeds and a plastic ventilation duct.

Multiservice penetration seals typically require fire batt or fire protection compound to complete the oversized aperture. Services are then sealed with individual firestop seals that are fitted within, or to, the overall seal.

In accordance with BSEN1366-3:2021 section 13.7, there must be a minimum of 100mm between penetration seals, unless tested otherwise. So, whilst direct-to-wall seals/single penetrations might be an attractive proposition, multiple services spaced at least 100mm between seals may not be achievable.

Therefore, a multiservice penetration fire batt seal which has been ‘tested otherwise’, with a lesser spacing requirement, may be a more appropriate option.

A pipe closure device that passes completely through the fire-separating element. May include an outer casing.

Smoke Barriers are smoke/gas-resistant barriers used to prevent the spread of smoke and/or gases.

Smoke dampers are driven by a motor, referred to as an actuator. A probe connected to the motor is installed in the duct's run and detects smoke, either in the air that has been extracted from or is being supplied to a room, or elsewhere within the duct's run. Once smoke is detected, the actuator automatically closes the smoke damper, and it remains closed until it is manually reopened.

Like fire seals, smoke seals are installed around the edges of doors and windows, but they function somewhat differently. While fire seals only become visible when they expand during a fire, smoke seals are always visible. They create a barrier that smoke finds difficult to pass through.

These intumescents produce a light char, a poor conductor of heat, which thus delays heat transfer. Ablative coatings, for example, contain a significant amount of hydrates. When the hydrates are heated, they decompose, and water vapour is released, which has a cooling effect. Once the water is spent, the insulation characteristics of the char that remains can slow down heat transfer from the exposed side to the unexposed side of an assembly.

Soft char products are typically used in thin-film intumescent coatings for fireproofing structural steel and firestop pillows. The expansion pressure created for these products is usually very low because the soft carbonaceous char has little substance, which is beneficial if the aim is to produce a layer of insulation.

The result of a factory and/or field method of joining or connecting two or more lengths of a fire-resistive joint system into a continuous entity.

Application of intumescent or endothermic paints, as well as fibrous or cementitious plasters to keep substrates like structural steel, electrical or mechanical services, valves, liquefied petroleum gas (LPG) vessels, vessel skirts, bulkheads, or decks below 140 °C for electrical components or approximately 500 °C for structural steel. This ensures these items remain operational.

Stability refers to the fire protection element’s capacity to withstand heat during a fire without collapsing, while still functioning properly. These elements include fire-rated partitions or barriers that are specifically designed to create compartmentation between rooms, zones, or escape routes. This reading is denoted by the letter “R.”

The Stay Put policy follows simple guidelines; those occupants of the flat where the fire started must evacuate the premises and summon the Fire Service. If a fire occurs in a common area, people in that area should leave the building and call the emergency services.

The remainder of the building’s occupants are often safer to remain in their flats, unless told otherwise by the Fire Service. As well as avoiding unnecessary evacuations, this also means that residents from unaffected flats are not blocking the stairways and exit routes, and the fire service, when they arrive, can safely evacuate residents floor by floor if need be.

The safety of residents staying in a building, however, relies on the presence and correctness of compartmentation.

Structural fire protection safeguards essential structural components, such as steel and joint systems, from fire damage. This is achieved through fireproofing materials like spray-on thin-film intumescent and endothermic substances such as gypsum-based plasters and cementitious products, mineral wool wraps, insulation, and fireproofing cladding, or by constructing the structure using concrete products.

Components of wood or metal that form a framework to which board facings are fixed to create a stud partition.

Substrate construction is a reference to the wall or floor system that forms the fire compartmentation. Different products and systems will provide different levels of fire resistance.

Whilst certain test evidence can be interchangeable for some other substrates (e.g. flexible wall data covers certain rigid wall scenarios) it is critical that the passive fire protection system tested scope of application covers the specific wall or floor type.

The purpose of a fire stop seal is to repair or maintain the fire resistance of a fire compartment and is, therefore, reliant on the performance of the substrate.

In effect, the fire stop seal can only ever be as good as the supporting construction so the starting point when identifying tested solutions is to identify what is being penetrated.

Person or organisation who owns the performance evidence of a system.

A technical assessment is a fire-resistance evaluation of an on-site application that relies on indirect test evidence. It uses established empirical methods of estimation and experience of fire testing conducted on similar firestop systems.

This extends the scope of application by determining the limits for the design based on the tested constructions and performances obtained. The assessment will evaluate the potential fire-resistance performance of the elements if they were tested in accordance with BS 476: Part 20: 1987.

The assessment must be prepared and checked by product assessors with the necessary competence, who subscribe to the principles outlined in the PFPF guidelines for undertaking assessments in lieu of fire tests.

The PFPF guidelines aim to give end-users confidence that assessments in the UK meet a satisfactory standard for use in lieu of fire tests for building control and other purposes.

Thermal conduction is the transfer of heat through all types of matter, such as solids, gases, and liquids. The heat transfer rate is determined by the material conducting heat and the temperature difference between the two products.

A conformity assessment process carried out by a body that is independent of both supplier and customer organisations. It confirms that products and services have met, and will continue to meet, the requirements of specified standards and other normative documents.

A hole made in a fire-rated wall or floor that completely passes through from one side to the other to run things such as pipes and cables.

A metal or plastic casing designed to accommodate cables, normally square or rectangle in section.

Intended for use in conditions exposed to all kinds of weathering, such as freezing temperatures, high UV, and rain. Materials that meet the requirements for type X also meet the requirements for all other types.

Intended for use at temperatures below 0°C with exposure to UV but no exposure to rain. Materials that meet requirements for type Y1 also meet the requirements for types Y2, Z1, and Z2.

Intended for use at temperatures below 0°C, but with no exposure to rain or UV. Materials that meet the requirements for type Y2 also meet the requirements for types Z1 and Z2.

Intended for use at internal conditions with high humidity, excluding temperatures below 0°C. Materials that meet the requirements for type Z1, also meet the requirements for type Z2.

Intended for use at internal conditions with humidity classes other than Z1, excluding temperatures below 0°C.

U-PVC (Unplasticized Polyvinyl Chloride) pipes and fittings, also known as rigid PVC, are used for all plumbing purposes in residential and commercial buildings. They are ideally suited for use in outdoor installations, concealed pipelines for cold water distribution, and at each floor level. U-PVC is known for having strong resistance against chemicals, sunlight, and oxidation from water. U-PVC is widely used in construction. It is durable, cheap, and easily worked.

Permeability is a material’s property that allows fluids (for example, water, water vapor, or oil) to pass through it to another medium without causing any damage. Permeability causes materials to deteriorate rapidly and leads to corrosion.

The yield strength of a bar of material is the maximum stress that can be applied along its axis before it begins to change shape.
